JYH Series-260 PCB/LED Photoelectric Teflon Tunnel Furnace

Custom processing: Yes
Application scope: models such as plastics, hardware components, electronic products, semiconductors, chips, PCBs, LEDs, etc
Chain type, chain plate type, stainless steel mesh belt type, Teflon type
Purpose: heating, drying, and heat treatment

Detail
Production characteristics:
1. Material of furnace shell: Made of 1.2 cold-rolled sheet metal through bending; (customizable according to customer requirements)
2. Material of the inner liner of the furnace body: Made of 1.0mm galvanized sheet; (Can be customized according to customer requirements)
3. Heating method: Utilizing finned stainless steel heating tubes and far-infrared heating tubes; (For special heating elements, please consult the seller)
4. Set temperature: room temperature +10℃~250℃; (temperature adjustable, for higher temperatures, please consult the seller)
5. Conveyor devices include: stainless steel mesh belt, Teflon mesh belt, chain plate, chain, and PVC belt; (optional)
6. Exterior paint of the stove body: The default paint color is computer white; (please consult the seller for special requirements)
7. Additional functions such as sensors can be installed; (please consult the seller for installation)
8. Insulation layer: Made of Sisal 80K environmentally friendly high-temperature cotton, with an insulation thickness of 50mm; (customizable according to customer requirements)
9. Machine feet: Made of 50*50 square tubes; (please consult the seller for sealing the entire bottom)
10. The above configuration can be adjusted or customized according to the actual needs of customers:
Note: Our company offers a diverse range of styles. Please feel free to contact us for inquiries: 13172457248 (also available on WeChat)
